HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment

Start Port: Guangzhou
Production Capacity: 10000 units/Month
Place of Origin: Guangdong, China
Payment: L/C, T/T, Western Union, Alibaba Trade Assurance, paypal
MOQ: 1 pcs
Model: LY-HFPL
Delivery Time: Within 7 working days
Certification: SGS, ISO 9001
Brand: OEM/Lvyuan
Inquiry
Share your love
Category: Tags: , , , , ,
HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment 5
The LY-HFPL filter cartridge is a new product developed by Lvyuan Water Purification Equipment Co.,Ltd. In Guangzhou, China. It has a 6 inch/152mm large diameters. It is made of 100% polypropylene media. The hard strong cage enables the high water flow filters to undertake a larger operation pressure during filtration process. The large diameter with big filter area insures to reduce the number of filter cartridges and the dimension of housing required. The long service life and high flow rate result in low investment and less manpower in many applications. This kind of LY-HFPL product has various applications on water treatment.

  Product Feature

  • ◪    All contaminants can be removed within the cartridges because of the flow direction.
  • ◪   Up to 110m³/h flow rate per one filter cartridge for water filtration.
  • ◪   Max. 50% reduction of the filter system.
  • ◪   Multi membrane layers for large dirt holding in the high flow filter elements.
  • ◪   Thermally bonded construction for stronger pressure resistance.
  • ◪   Handle design quick installation, safety and reduce the cost.

Product Parameter

Product Name Repalcement High flow water filter cartridge 60 inch (LY-HFPL)
Filter media PP/Polypropylene membrane
Support PP/Polypropylene
Core/End cap PP/Polypropylene
Seal material Silicone/EPDM/VITON/PTFE/NBR
Outer diameter 6”(152mm)
Inner diameter 3.5 inch(89mm)
Length 20”, 40”, 60”, Customized
Max.operating temperature 82℃
Micron rating(μm) 1, 4, 5, 10, 15, 20, 40, 70, 100

Product Details

HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment 6
part.1

★ Graded filtration pore sizes in one high flow element.

★ Easier and more convinient installation and replaced.

★ Pleated with optimized membrane structure, better filtration and efficiency.

★ U-shaped sealing groove ensures high filtration efficiency.

★ From filter inside to outside filtration, all impurities are trapped inside the filter.

Product Applications

HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment 7

Municipal tap water, Prefiltration of RO, Pre treatment of sea water desalination

HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment 8
Condensate water filtration, hot water recovery in power generation
HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment 9
API, solvents, and water filtration in BioPharm market
HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment 10
The filtration of bottled water, high fructose, edible oil, soft drinks and milk
HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment 11
Paints and coatings, Petrochemical, refineries, CD/DVD, magnetic media, Petrochemical, Refineries
HF Series 5/10 Micron High flow filter Pleated Sediment Cartridge For Water Filter treatment 12
Microelectronics, film, fiber and resin
